Mebay ATS320DC Auto Transfer Switch Controller with LCD Display
Mebay ATS320DC Auto Transfer Switch Controller with LCD Display
  • Mebay ATS320DC Auto Transfer Switch Controller with LCD Display
  • Mebay ATS320DC Auto Transfer Switch Controller with LCD Display
  • Mebay ATS320DC Auto Transfer Switch Controller with LCD Display
  • Mebay ATS320DC Auto Transfer Switch Controller with LCD Display

Mebay ATS320DC Auto Transfer Switch Controller with LCD Display

Product Details:
Place of Origin: China
Brand Name: Mebay
Certification: ISO9001
Model Number: ATS320DC
Detail Information
Place of Origin:
China
Brand Name:
Mebay
Certification:
ISO9001
Model Number:
ATS320DC
Model Number:
ATS320DC
Quality:
100% Original
Stock:
Yes
Warranty:
1year
Packaging:
Carton
Type:
Control Panel
Highlight:

High Light

Highlight:

car engine control module

,

diesel generator controller

,

Electronic Digital Meter

Trading Information
Minimum Order Quantity:
5
Price:
$38-$45
Packaging Details:
carton
Delivery Time:
5-10 work days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:
In stock
Product Description
Mebay ATS320DC Auto Transfer Switch Controller with LCD Display
Product Specifications
Attribute Value
Model Number ATS320DC
Quality 100% Original
Stock Yes
Warranty 1 year
Packaging Carton
Type Control Panel
Product Overview
Brand Name Mebay
Place of Origin China
Part Number ATS320DC
After-sales Service Video Technical Support, Online Support
Marketing Type Ordinary Product
Certificate ISO9001
The Mebay ATS320DC is an automatic transfer switch controller designed for mains/generator applications. It features automatic and manual control modes for dual power switching, with comprehensive LCD display for monitoring system parameters and fault conditions. The controller provides reliable protection when generator operation is abnormal.
Key Features
  • 32-bit dual core high performance microcontroller
  • LCD display with Chinese/English language options (additional languages available)
  • Monitors and displays generator, mains, phase, and other critical parameters
  • Automatic/Manual operation modes with manual override capability
  • Compatible with various AC systems (3-phase 4-wire, single-phase 2-wire, 2-phase 3-wire)
  • Clear input/output status indication
  • 3 relay outputs and 3 configurable switch inputs
  • USB port for parameter configuration and real-time monitoring (works without power)
  • Comprehensive protection functions with fault display
  • IP65 waterproof rating with standard rubber gasket
  • Modular design with European connectors for easy installation and maintenance
Functional Capabilities
The controller displays single-phase power generation voltage, frequency, mains voltage, and frequency. It indicates working mode (manual/automatic/test/shutdown) and ATS switch status via LED indicators. All parameters can be configured through front panel buttons or via PC using the programmable USB interface.
Mebay ATS320DC Auto Transfer Switch Controller with LCD Display 0

Tags:

diesel genset control module,

LCD control panel,

diesel generator module
