DEIF SIM-Q MKII Insulation Monitor for AC/DC Networks

DEIF SIM-Q MKII Insulation Monitor for AC/DC Networks

Product Details:
Place of Origin: The Kingdom of Denmark
Brand Name: DEIF
Certification: CE,RoHS,ISO9001
Model Number: SIM-Q MKII
Detail Information
Place of Origin:
The Kingdom of Denmark
Brand Name:
DEIF
Certification:
CE,RoHS,ISO9001
Model Number:
SIM-Q MKII
Warranty:
1 Year
Stock:
Yes
Quality:
100% Original
Packing:
Carton
Selling Units:
Single Item
Size:
96*96*90.5mm
Weight:
0.39kg
Color:
Black
Highlight:

High Light

Highlight:

car engine control module

,

diesel generator controller

,

Electronic Digital Meter

Trading Information
Minimum Order Quantity:
1
Price:
U$2200
Packaging Details:
Carton
Delivery Time:
5-8 Days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:
In Stock
Product Description
WESPC Original Genuine DEIF SIM-Q MKII Insulation Monitor Insulation Table
Product Specifications
Attribute Value
Warranty 1 Year
Stock Availability In Stock
Quality 100% Original
Packing Carton
Selling Units Single item
Size 96*96*90.5mm
Weight 0.39kg
Color Black
Model Number SIM-Q MKII
Type Insulation Table
Product Description

The WESPC Original AGC-4 MKII DEIF Controller Generator Parts & Accessories include the SIM-Q MKII Insulation Monitoring Device, designed for high-end monitoring of AC/DC networks with high leakage capacitance.

Key Features
  • Patented measuring method using ±25 V DC voltage superimposed to monitored system
  • Automatic measuring cycle compensates for network capacitances and AC/DC components
  • Available in low frequency (LF) version for thruster systems (5-20Hz frequency variations)
  • Three selectable operation modes for optimal performance
Operation Modes
  • Normal mode (IMD type: AC/DC): Long measuring cycles (10-7,000 seconds) with immunity to disturbances
  • Fast mode (IMD type: AC): Short response time for fault location when multiple groups need switching
  • Test mode: Self-test of warning/relay function and set point adjustment with rear-mounted adjustment knob
After-sales Support

Includes video technical support and online support for all your installation and maintenance needs.
