| Place of Origin: | China |
| Brand Name: | Fortrust |
| Certification: | CE,RoHS,ISO9001 |
| Model Number: | GEC4520-458-4G |
WESPC Original GEC4520-458-4G Generator Control Panel Auto Mains Failure Controller
| Brand Name | Fortrust |
| Place of Origin | China |
| Model Number | GEC4520-458-4G |
| Marketing Type | Ordinary Product |
| Certificatr | ISO9001 |
| Stock | Yes |
GEC4500 Series Controllers – Technical Overview
Model Specifications:
GEC4510
Application: Standalone generator automation
Core Function: Remote start/stop control via dry contact signals
Operation: Automatic sequencing with status feedback
Typical Use: Basic single generator set control systems
GEC4520
Enhanced Features:
Utility power detection (voltage/frequency monitoring)
Automatic Mains Failure (AMF) transfer switching
Protection: Grid loss detection and automatic generator start
Application: Single utility source + single generator backup systems
Advantage: Uninterrupted power transfer during grid failures
GEC4510-4G
Connectivity: 4G LTE cellular communication
Remote Functions:
Cloud-based real-time monitoring
Remote start/stop command execution
Online parameter configuration
Historical data analysis (startup curves/fault records)
Protocol Support: MQTT/Modbus TCP for cloud integration
GEC4520-4G
Premium Features:
Complete AMF functionality with grid synchronization
4G cloud connectivity with dual SIM support
Remote SCADA integration capability
Advanced power quality monitoring
Diagnostic Tools:
Remote waveform analysis
Performance trending reports
Predictive maintenance alerts
Technical Platform:
Processor: 32-bit ARM Cortex-M4 core
Memory: 4MB flash, 1MB RAM
Communication: RS485, USB, Ethernet (4G models)
Display: 320x240 LCD with multi-language support
Operating Voltage: 8-35VDC wide range input
Environment: -40°C to +85°C operating temperature
Series Architecture:
Hardware: Unified mechanical design and mounting pattern
Software: Common firmware platform with feature licensing
Scalability: Modular functionality expansion
Compatibility: Consistent wiring and terminal arrangements
The GEC4500 series represents a scalable architecture that maintains hardware consistency while offering graduated functionality levels, from basic local control to advanced cloud-based power management systems. All models share the same robust construction and reliability features, ensuring compatibility across different automation requirements.
Certification: CE, RoHS, ISO 9001 compliant
Warranty: 3 years standard warranty coverage
