| Place of Origin: | China |
| Brand Name: | SMARTGEN |
| Certification: | CE,RoHS,ISO9001 |
| Model Number: | BACM2420 |
WESPC Original Smartgen BACM2420 Battery Charger Floating Charger
| Size | 254*156*68mm |
| Weight | 2.2kg |
| Model Number | BACM2420 |
| Brand Name | Smartgen |
| After-sales Service Provided | Video Technical Support,Online Support |
| Markrting Type | Ordinary Product |
| Warranty | 1 year |
| Stock | Yes |
BACM2420 battery charger is intelligent and multi-function which is specially designed for meet the charging characteristics of the lead-acid engine starter batteries. Suitable for 24V or 12V battery and the maximum charge current is 20A.
PERFORMANCE AND CHARACTERISTICS:
Switch power supply structure, wide AC voltage input range, small size, light weight, high efficiency;
Users can select automatic two-stage charging process or automatic three-stage charging process according to needs. Both two charging processes are carried out according to storage battery charging characteristics, which can prevent overcharging and significantly prolong battery lifetime;
Built-in PFC circuit, which allows to calibrate the power factor up to 0.99;
Battery voltage detection ports, which can detect the battery voltage at real time.
Battery under voltage output port; it will output low level immediately after the battery voltage has fallen below the set value after preset delay.
Temperature sensor port, which allows monitoring the battery temperature at real time; and temperature compensation function, which can prevent too high battery temperature effectively;
Mains failure alarm port; It will output low level when the AC input is interrupted;
Standard RS485 serial communication port.
Default suitable for 24V battery pack; it can be changed to 12V battery pack by changing configuration information; rated charging current is 20A;
External LED status display: Full charged indication (Green light) and charging indication (Red light).
