| Place of Origin: | China |
| Brand Name: | WESPC |
| Certification: | ISO9001 |
| Model Number: | 015-0096-07 |
WESPC Coolant Temperature Sensor 015-0096-07 For Perkins Engine 1100CC
| Brand Name | WESPC |
| Place of Origin | China |
|
Part Number |
015-0096-07 |
| After-sales Service Provided | Video Technical Support, Online Support |
| Marketing Type | Ordinary Product |
| Certificate | ISO9001 |
| Warranty | 1 Year |
| Stock | Yes |
Application:
Technical specifications:
Thread size M12 × 1.75, 19 mm hex, brass sensor body with a PBT 30 % GF connector and Fluorocarbon O-ring for reliable sealing. Operating range ‑40 °C to 185 °C, NTC thermistor element. Cold resistance 2 kΩ–3 kΩ at 20 °C, hot resistance 200 Ω–300 Ω at 90 °C.
Material & performance features:
Sensor body machined from high-grade brass for superior thermal conductivity and corrosion resistance. Electronics fully encapsulated in epoxy for vibration and moisture protection. Connector sealed to IP67, ensuring long-term durability in harsh engine environments.
Interchange part numbers:
PERKINS 4181A022, MASSEY FERGUSON 3638721M91, LANDINI 747602M91, 1158145, WG1104543
