| Place of Origin: | China |
| Brand Name: | WESPC |
| Certification: | ISO9001 |
| Model Number: | 185426290 |
WESPC Temperature Sensor 185426290 For Perkins T4.236 and AT4.236
| Brand Name | WESPC |
| Place of Origin | China |
|
Part Number |
185426290 |
| After-sales Service Provided | Video Technical Support, Online Support |
| Marketing Type | Ordinary Product |
| Certificate | ISO9001 |
| Warranty | 1 Year |
| Stock | Yes |
Application:
Technical specifications:
Thread interface M14 × 1.5 parallel with 19 mm hex and 18 mm probe reach for direct insertion into the thermostat housing or cylinder-head coolant gallery. Sensing span –40 °C to +140 °C via a precision NTC thermistor calibrated 2 500 Ω @ 20 °C, 300 Ω @ 80 °C, 120 Ω @ 110 °C, tolerance ±2 %. Electrical connection is a two-pin sealed Deutsch DT04-2P, IP67 rated, vibration resistant to 50 g, overall sensor length 52 mm, mass 46 g.
Material & performance features:
Probe body is machined from 1.4571 (AISI 316Ti) stainless steel for total immunity to glycol, long-life OAT coolants and galvanic corrosion; a copper crush-washer and fluorosilicone O-ring guarantee leak-free sealing up to 3 bar system pressure. Electronics are fully potted in high-temperature epoxy, thermal-shock tested 1 000 cycles –40 °C ↔ +150 °C, salt-spray tested 96 h per ASTM B117, EMI-suppressed circuitry compliant with SAE J1113-42 for reliable ECU feedback, MTBF > 500 000 engine hours.
Interchange part numbers:
185426290, 10000-59838, 4224847M1, 4222214M1, 2755A028.
