| Place of Origin: | China |
| Brand Name: | Mebay |
| Certification: | ISO9001 |
| Model Number: | GV13DC-12 |
WESPC Original GV13DC-12 Digital Meter DC Voltage Frequency Monitoring
| Working power | DC8～36 V |
| Consuming power | MAX:1 W |
| Operation temperature range | -30℃ ～ 70℃ |
| Size (W * H * D) | 58mm * 54mm * 41mm |
| Installation Size(W * H) | 47mm * 37mm |
| Weight | 55G |
Summary
GV13DC-12 is one light and low price-orientated module used for checking and demonstrating Voltage, Frequency and accumulating time of generator. This module can replace old meters, for it can be one with multi-functions. It uses normal screw for connection which is more convenient for installation.
Features
Voltage, frequency and accumulating time can be checked and demonstrated in the mean time;
Results shown by 4-position digital LED tube
Self-recycling of parameters
with Page Turning Buttons
DC voltage supply
Parameter demonstration
Phase voltage
Frequency
Cumulative running time
Current run time
Measuring range and accuracy
Voltage: ac30-450v, error ≤± 1%
Frequency: 20-70hz, error ≤± 0.5%
Cumulative operation time: 0-9999h
Current running time: 0-999.9h
