WESPC Wiring Harness 238-1948 For Cater E320C Hydraulic Excavator
  • WESPC Wiring Harness 238-1948 For Cater E320C Hydraulic Excavator
  • WESPC Wiring Harness 238-1948 For Cater E320C Hydraulic Excavator
  • WESPC Wiring Harness 238-1948 For Cater E320C Hydraulic Excavator
  • WESPC Wiring Harness 238-1948 For Cater E320C Hydraulic Excavator
  • WESPC Wiring Harness 238-1948 For Cater E320C Hydraulic Excavator

WESPC Wiring Harness 238-1948 For Cater E320C Hydraulic Excavator

Product Details:
Place of Origin: China
Brand Name: WESPC
Certification: ISO9001
Model Number: 238-1948
Detail Information
Place of Origin:
China
Brand Name:
WESPC
Certification:
ISO9001
Model Number:
238-1948
Product Name:
Wiring Harness 238-1948
Condition:
100%new
Quality Class:
High-Quality
Stock:
Yes
Warranty:
1year
Packaging:
Carton
Highlight:

High Light

Highlight:

Cater E320C Wiring Harness

,

Excavator Wiring Harness 238-1948

,

Wiring Harness 238-1948

Trading Information
Minimum Order Quantity:
10
Price:
$800-$825(1 Piece)
Packaging Details:
carton
Delivery Time:
5-10 work days
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:
In stock
Product Description
WESPC Wiring Harness 238-1948 for Cater E320C Hydraulic Excavator
Brand Name WESPC
Place of Origin China
Part Number 238-1948
After-sales Service Video Technical Support, Online Support
Marketing Type Ordinary Product
Certificate ISO9001
Warranty 1 Year
Stock Yes
Application
The 238-1948 Wiring Harness is specifically engineered as a Chassis Line Wiring Harness for Cater E320C hydraulic excavator platforms. This essential component serves as the primary electrical backbone, connecting the operator cab to the main chassis system to facilitate reliable signal transmission and power distribution between critical machine components. Designed for extensive use across the Cater 320C/E320C series excavators and compatible variants, this harness supports the electrical infrastructure for hydraulic control systems, sensor arrays, lighting circuits, and auxiliary equipment. The routing extends through the machine's boom, stick, and frame structures, connecting chassis-mounted solenoids, pressure sensors, travel motors, swing mechanisms, and safety interlock systems. This component is also compatible with related chassis harness configurations in the 320CU series and other C-series hydraulic excavators requiring robust cab-to-chassis electrical connectivity.
Technical Specifications
  • Cable Certification: UL, VDE, CE, RoHS, ISO9001 compliant materials ensuring international safety and quality standards
  • Application Type: Chassis line main harness (Cab to Chassis connection)
  • Compatible Equipment: Cater E320C, 320C, 320CU hydraulic excavators
  • Voltage Rating: Designed for 24V DC heavy-duty construction equipment electrical systems
  • Connector Systems: Multi-pin configurations utilizing Deutsch, JAE, Hirose, Molex, and AMP terminal technologies
  • Conductor Gauge: Automotive-grade copper conductors with appropriate gauge ratings for high-current and signal transmission applications
  • Insulation Materials: Multi-layer construction featuring rubber, silicone, polyethylene, or polytetrafluoroethylene (PTFE) compounds
  • Protection Rating: Sealed connectors with IP67-rated environmental protection against dust and moisture ingress
  • Flexibility Rating: High-flexibility cable construction accommodating continuous articulation and vibration typical of hydraulic excavator operations
  • Temperature Range: Engineered for extreme temperature differentials encountered in heavy construction environments
  • Harness Configuration: Multi-circuit design with strategic branching points for connection to hydraulic valve solenoids, limit switches, and monitoring sensors
Material & Performance Features
This wiring harness is manufactured using premium-grade cable materials certified to UL, CE, VDE, SAA, and CB international standards, ensuring exceptional electrical safety and consistent performance. The conductors feature high-purity oxygen-free copper with precision tin plating, delivering superior electrical conductivity and corrosion resistance in harsh operating environments exposed to hydraulic fluids, abrasion, and weather elements. Connector housings are constructed from high-impact resistant engineering polymers including rubber, silicone, polyethylene, and polytetrafluoroethylene (PTFE), providing excellent dielectric properties and mechanical durability. The harness assembly incorporates precision-molded seals and grommets to prevent moisture ingress and dust contamination at connection points. All materials conform to RoHS environmental standards, eliminating hazardous substances and ensuring eco-friendly operation.
Interchange Part Numbers
238-1948; 2381948; 163-6749; 186-4605; 197-4289; 1974289
WESPC Wiring Harness 238-1948 For Cater E320C Hydraulic Excavator 0

Tags:

wiring harness assembly,

diesel engine wiring harness,

diesel wiring harness
