| สถานที่กำเนิด: | จีน |
| ชื่อแบรนด์: | Mebay |
| ได้รับการรับรอง: | ISO9001 |
| หมายเลขรุ่น: | DC50DR MK3 |
WESPEC Original DC50DR MK3 Original Auto Remote Start Generator Controller
| DC Supply | DC 8～36V |
| Power Consumption | MAX 3W |
| Size |
100mm*100mm*77mm |
| Panel cut-out | 91mm*91mm |
| Operation Temperature | -30℃～70℃ |
| Storage Condition | -40℃～85℃ |
Overview:
This series of controllers is designed specifically for the starting, stopping, parameter monitoring, and fault monitoring of diesel, gasoline, and gas generator sets, and has parameter setting functions
This controller adopts a 3.5-inch 240 * 128 high-resolution LCD display with a brand new original UI design, and parameters are displayed through analog pointers and numbers. The LCD screen can simultaneously display multiple fault states and effectively implement protective shutdown when the generator set is not working properly.
The controller has built-in display interfaces in Simplified Chinese, English, and other languages that can be selected, and the language interface can be customized according to customer requirements. All parameters of the controller can be adjusted through the controller panel buttons, or adjusted and monitored through USB or RS485 interfaces on a PC, and can be widely used in various types of generator automation systems.
Performance and Features
The DC5xD MK3 series has four models:
DC50D MK3: Used for single machine automation, controlling the automatic start and stop of the generator set through remote start signals;
DC52D MK3: On the basis of DC50D MK3, the addition of mains power monitoring and automatic switching control (AMF) function between mains power and power generation is suitable for a single machine automation system consisting of one mains power and one generator set.
DC50DR MK3: Add RS485 interface on the basis of DC50D MK3;
DC52DR MK3: Add RS485 interface on the basis of DC52D MK3;
