| Place of Origin: | Denmark |
| Brand Name: | DEIF |
| Certification: | CE,RoHS,ISO9001 |
| Model Number: | IOM220 |
WESPC Original HAT530N ATS Controller Dual Power LED LINK Remote Transfer
| Size | 115*75*25mm |
| Weight | 0.28kg |
| Generator Type | Diesel Generator |
| Communication Interface |
Modbus RTU/CANopen |
| Operating Humidity |
10–90% (non-condensing) |
| Operating Temp | -25°C to +70°C |
| Protection Class | IP20 |
| Input Voltage | 24V DC |
| MOQ | 1PCS |
| Material |
Plastic |
Overview:
• CANbus interface with automatic address selection
• Analogue output/governor interface
◦ 0-20 mA ◦ ±25 mA ◦ 0-10 V DC (adjustable)
◦ ±12 V DC (adjustable)
• Analogue output/AVR interface
◦ 0-20 mA ◦ ±25 mA
◦ 0-10 V DC (adjustable)
◦ ±12 V DC (adjustable)
• TTL interface to PC
◦ Uses option J5 (RS232 to TTL converter cable)
◦ Only for downloading firmware updates
• LEDs for unit status and CAN status
◦ 2-coloured LEDs
◦ Green: System OK; Red: Fai
