| Place of Origin: | China |
| Brand Name: | Fortrust |
| Certification: | CE,RoHS,ISO9001 |
| Model Number: | GEC4510-485-CAN |
WESPC Original GEC4510-485-CAN Diesel Generator Set Controller Module
| Brand Name | Fortrust |
| Place of Origin | China |
| Model Number | GEC4510-485-CAN |
| Marketing Type | Ordinary Product |
| Certificatr | ISO9001 |
| Stock | Yes |
The GEC4500 IoT Generator Set Controller is engineered for intelligent automation and monitoring of single diesel generator sets. It supports automatic start/stop, real-time data acquisition, full alarm protection, and complete “three-remote” functionality—telemetry, telecommand, and telesignal.
Equipped with a color LCD graphic interface supporting six languages (including Chinese, English, Russian, and Spanish), the controller offers intuitive operation and global usability. Built on 32-bit microprocessor architecture, it ensures precise parameter measurement, flexible configuration, and programmable timing and thresholds. Users can adjust most settings via the front panel, while full system programming is available through RS485 or USB using PC software.
The controller integrates with cloud-based monitoring modules via RS485, enabling continuous internet connectivity. Once connected to the cloud server, it uploads real-time data, allowing users to monitor status, review historical logs, and configure parameters remotely via mobile apps or desktop platforms. Wi-Fi functionality supports local diagnostics and calibration, with optional remote technical assistance available.
Compact, durable, and easy to install, the GEC4500 series is suitable for a wide range of generator automation applications across diverse environments.
Performance and Features:
Model Variants & Functions:
GEC4510: Basic automation controller for remote start/stop of single generator units.
GEC4520: Adds mains power detection and automatic transfer switching (AMF); ideal for one-grid-one-generator systems.
GEC4510-4G: Includes remote monitoring, start/stop control, parameter adjustment, and curve analysis.
GEC4520-4G: Combines AMF functionality with full remote control, configuration, and performance tracking.
Key Features Summary:
320×240 color LCD with backlight and touch-button interface
Six-language support: Simplified Chinese, English, Russian, Spanish, Turkish, French
Acrylic screen protection; silicone keypad for extreme temperatures
RS485 interface with MODBUS protocol
Compatible with 3-phase 4-wire, single-phase 2-wire, and split-phase systems
Measures generator/grid voltage, current, frequency, and power
Grid protection: over/under voltage, phase loss
Generator protection: over/under voltage/frequency, overcurrent, overpower
Three fixed analog sensors: water temp, oil pressure, fuel level
One programmable sensor for temp/pressure/level or digital input
Four programmable relay outputs: shutdown, idle, preheat, speed control
EEPROM-based parameter storage; editable via panel or PC
Configurable I/O ports for flexible deployment
Digital parameter tuning replaces analog potentiometers
Built-in Wi-Fi for app-based curve analysis and calibration
USB BootLoader firmware upgrade support
Maintenance alerts by date or runtime with configurable actions
Multiple start success conditions: RPM, output, oil pressure
Supports internal/external IoT gateways for remote access
Historical log with real-time clock (up to 80 records)
Wide power input range: 8–35V DC
Flame-retardant ABS housing; modular design with pluggable terminals
